220V 160mm HDPE Thermofusion Welder | Hydraulic Data Logger Ready

Product Details:

Contact Now

Detailed Product Description

Highlight:

220V HDPE thermofusion welder

160mm hydraulic data logger welder

manual butt fusion welding machine

HDPE Butt Fusion Welding Machine Description

This HDPE butt fusion welding machine joins pipes and fittings made of PE, PP and PVDF with easy operation suitable for all complex work conditions. The system comprises a basic frame, hydraulic unit, electric planing tool, PTFE-coated heating plate, and support brackets. When equipped with the optional data logger, the welding process operates in a semi-automatic mode — continuously repeating welding cycles with automatic preset parameter control. The data logger stores up to 1000 welding cycles and exports encrypted EXCEL reports via USB to a PC/laptop.

HDPE Butt Fusion Welding Machine Specification

Product Name		DVS2207-1(08/2007) 160MM HDPE Butt Fusion Welding Machine
Model		SMD-B160/50H
Pipe size (mm)		50,63,75,90,110,125,140,160
Application		Butt Fusion Welding HDPE pipe
Heating plate Max. Temperature		270℃
Temp.deviation in surface (170-250 ℃)		≤±7℃
Pressures Adjustable Ranges		0-6.3Mpa
Working Voltage		220V , 50/60HZ , single phase
Heating plate power		1KW
Planing tool power		1.1KW
Hydraulic unit power		0.75KW
Total Power		2.85KW
Weight		106KG
Packing	Cases	3 plywood cases
	Volume	0.58 CBM

Available Options
