800mm HDPE Pipe Butt Fusion Welder 380V | Large Diameter Manual

Product Details:

Contact Now

Detailed Product Description

Highlight:

800mm HDPE pipe butt fusion welder

large diameter manual fusion welder

380V HDPE pipe welding machine

Butt Fusion Welder for Welding HDPE Pipes Description

The butt welding method of joining polyethylene (PE) pipe requires the combined application of appropriate temperature, time and pressure to ensure a sound weld. Operators should take care to determine the suitability of materials for butt welding. Join only pipes and fittings made from the same raw materials, e.g. PE to PE, PP to PP, PVDF to PVDF.

Butt Fusion Welder for Welding HDPE Pipes Specification

Product Name		Butt Fusion Welder for Welding HDPE Pipes
Model		SMD-B800/450H
Pipe size (MM)		450-800MM
Application		PE Pipe & Fitting Welding
Heating plate Max. Temperature		270℃
Temp.deviation in surface (170-250 ℃)		≤±7℃
Pressures Adjustable Ranges		0-16Mpa
Working Voltage		380/415V 50/60HZ
Heating plate power		12.5KW
Planing tool power		2.2KW
Hydraulic unit power		3KW
Crane Power		0.5KW
Total Power		18.2KW
Weight		1360KG
Packing	Cases	5 plywood cases
	Volume	8.39CBM

FAQ

1. ZEMOWELD: comprehensive manufacturer and experienced exporter of thermoplastic welding equipment from China.
2. Quality: pre-production samples + final inspection.
3. Products: Butt Fusion, Electrofusion, PPR, Automatic, Fittings, Pipe Tools.
4. CE/ISO/BV/SGS/CNAS certifications. 40mm to 3000mm welder range.
5. Delivery: FOB/CFR/CIF/EXW/FAS/CIP/FCA/CPT/DDP/DDU. Payment: USD/EUR/CNY via T/T, L/C, D/P, D/A, , PayPal, Western Union.

Warranty

ISO21307:2011(E), ISO12176-1 and DVS2207/1(08/2007) compliant.
24-month international warranty. Free replacement of defective parts.
