Name: Butt Fusion Welder 800mm For HDPE Pipes | ISO 21307 Standard
Brand: HEBEI ZEMO TECHNOLOGY CO., LTD.
Price: 50.00 USD
Availability: InStock

Home Products Manual Butt Fusion Welding Machine

Butt Fusion Welder 800mm For HDPE Pipes | ISO 21307 Standard

Product Details:

Contact Now

Detailed Product Description

Highlight:

800mm HDPE pipe fusion welder

manual butt fusion welding machine

ISO 21307 standard fusion welder

Butt Fusion Welder for HDPE Pipes Description

Butt welding of polyethylene (PE) pipe demands the precise combination of temperature, time and pressure for a sound, durable weld. Operators must verify material compatibility before welding — only join pipes and fittings from identical raw materials: PE to PE, PP to PP, PVDF to PVDF. Proper surface preparation and procedural adherence are essential for maximum joint integrity.

Butt Fusion Welder for Welding HDPE Pipes Specification

Product Name		Butt Fusion Welder for Welding HDPE Pipes
Model		SMD-B800/450H
Pipe size (MM)		450-800MM
Application		PE Pipe & Fitting Welding
Heating plate Max. Temperature		270℃
Temp.deviation in surface (170-250 ℃)		≤±7℃
Pressures Adjustable Ranges		0-16Mpa
Working Voltage		380/415V 50/60HZ
Heating plate power		12.5KW
Planing tool power		2.2KW
Hydraulic unit power		3KW
Crane Power		0.5KW
Total Power		18.2KW
Weight		1360KG
Packing	Cases	5 plywood cases
	Volume	8.39CBM

FAQ

1. ZEMOWELD: comprehensive thermoplastic welding equipment manufacturer and global exporter based in China.
2. Quality: pre-production samples verified + final inspection guaranteed.
3. Products: Butt Fusion, Electrofusion, PPR, Automatic, Fittings, Pipe Tools.
4. Certifications: CE, ISO, BV, SGS, CNAS. Welder range: 40mm to 3000mm.
5. Delivery: FOB/CFR/CIF/EXW/FAS/CIP/FCA/CPT/DDP/DDU. Payment currencies: USD, EUR, CNY. Methods: T/T, L/C, D/P, D/A, , PayPal, Western Union.

Quality Standards

ISO21307:2011(E), ISO12176-1 and DVS2207/1(08/2007) compliant.
24-month international warranty with free defective part replacement.
