Single Phase 220V HDPE Butt Fusion Welder | Manual CE Certified

Product Details:

Contact Now

Detailed Product Description

Highlight:

Single Phase 220V HDPE Butt Fusion Welder

Manual Butt Fusion Welding Machine CE Certified

HDPE Butt Fusion Welder with Manual Operation

Manual Butt Weld Fusion Machine Description

This manual butt weld fusion machine joins PE, PP and PVDF pipes and fittings with reliable performance in any field condition. The complete system integrates a basic frame, hydraulic hand pump, electric planing tool, PTFE-coated heating plate, and support brackets. Simple controls ensure operators can achieve consistent, high-quality welds with minimal training.

Manual Butt Weld Fusion Machine Specification

product name		160MM Manual Butt Weld Fusion Machine
Model		SMD-B160/50M
Pipe size (mm)		50,63,75,90,110,125,140,160
Pipe material		PE PP PVDF PPR HDPE etc
Heating plate Max. Temperature		270℃
application		Butt Weld Fusion PE PP PVDF PPR HDPE etc
Temp.deviation in surface (170-250 ℃)		≤±7℃
Working Voltage		220V , 50/60HZ , single phase
Heating plate power		1KW
Planing tool power		0.7KW
Total Power		1.7KW
Weight		44KG
Packing	Cases	2 plywood cases
	Volume	0.31CBM

Performance Highlights

Dupont PTFE anti-stick coated heating plate with independent digital temperature regulation.
Electric planer for clean, parallel end face preparation.
Lightweight high-strength aluminum alloy construction — portable and durable.
Low starting pressure protects small-diameter pipes during fusion.
Dual-channel timer independently monitors soak and cooling cycles.
High-precision shockproof pressure gauge for real-time force monitoring.

Warranty & Standards

Compliant with ISO21307:2011(E), ISO12176-1, DVS2207/1(08/2007).
24-month international warranty on all components and labor.
