Four Clamp 200mm HDPE Manual Butt Fusion Welder | PP PE PVDF

Product Details:

Contact Now

Detailed Product Description

Highlight:

HDPE manual butt fusion welder

PP PE PVDF welding machine

200mm manual butt fusion welder

Four Clamp Manual Butt Welding Machine

This four-ring manual butt fusion welding machine is engineered for PE, PP, PB, and PVDF thermoplastic pipes and fittings in both trench and on-site applications. The four-clamp design provides superior pipe alignment and holding stability compared to standard two-clamp configurations. We maintain regular size inventory for prompt delivery at competitive wholesale pricing.

Manual HDPE Butt Welding Machine Specification

Product name		200MM Four Clamps Manual HDPE Butt welding machine
Model		SMD-B200/50M
Pipe size (mm)		50,63,75,90,110,125,140,160 180,200
Pipe material		PE PP PVDF PPR HDPE etc
Heating plate Max. Temperature		270℃
application		Butt Weld Fusion PE PP PVDF PPR HDPE etc
Temp.deviation in surface (170-250 ℃)		≤±7℃
Working Voltage		220V , 50/60HZ , single phase
Heating plate power		1KW
Planing tool power		0.7KW
Total Power		1.7KW
Weight		44KG
Packing	Cases	2 plywood cases
	Volume	0.31CBM

Advantages

Four-clamp centering system for superior pipe grip and alignment.
Robust steel frame withstands harsh field environments.
Quick-release clamps reduce setup time between welds.
Standardized inserts cover full 50-200mm range.

FAQ

1. ZEMOWELD: 20+ years thermoplastic welding equipment manufacturer in China.
2. Quality: pre-production samples + final inspection.
3. Products: Butt Fusion, Electrofusion, PPR, Automatic, Fittings, Pipe Tools.
4. CE/ISO/BV/SGS/CNAS certified. 40-3000mm range.
5. FOB/CFR/CIF/EXW. T/T, L/C, D/P, D/A, Western Union, PayPal.
