Name: Precision 160mm PE Butt Fusion Welder 220V Manual Operation
Brand: HEBEI ZEMO TECHNOLOGY CO., LTD.
Price: 50.00 USD
Availability: InStock

Home Products Manual Butt Fusion Welding Machine

Precision 160mm PE Butt Fusion Welder 220V Manual Operation

Product Details:

Contact Now

Detailed Product Description

Highlight:

160mm PE butt fusion welder

manual butt fusion welding machine 220V

precision PE welder with warranty

Precision Manual Butt Fusion Welder Description

Engineered for reliable on-site thermoplastic pipe joining, this precision manual butt fusion welder delivers consistent, high-strength welds for PE, PP and PVDF pipes and fittings ranging from 50mm to 160mm. The integrated system combines a sturdy basic frame, hydraulic hand pump unit, electric planing tool, PTFE-coated heating plate, and support brackets — all optimized for easy operation in trench, ditch, and complex field conditions.

Manual Butt Weld Fusion Machine Specification

product name		160MM Manual Butt Weld Fusion Machine
Model		SMD-B160/50M
Pipe size (mm)		50,63,75,90,110,125,140,160
Pipe material		PE PP PVDF PPR HDPE etc
Heating plate Max. Temperature		270℃
application		Butt Weld Fusion PE PP PVDF PPR HDPE etc
Temp.deviation in surface (170-250 ℃)		≤±7℃
Working Voltage		220V , 50/60HZ , single phase
Heating plate power		1KW
Planing tool power		0.7KW
Total Power		1.7KW
Weight		44KG
Packing	Cases	2 plywood cases
	Volume	0.31CBM

Performance Advantages

Advanced PTFE anti-stick coated heating plate with independent digital temperature controller for uniform heat distribution.
Electric-powered planing tool ensures perfectly parallel pipe end preparation.
Lightweight high-strength aluminum alloy frame construction — compact footprint ideal for confined workspaces.
Ultra-low starting pressure guarantees reliable fusion on small-diameter pipes.
Dual-channel digital timer independently tracks soaking and cooling phase durations.
Shock-resistant precision pressure gauge provides clear, real-time force readings.

Quality Assurance & After-Sales Support

Fully compliant with ISO21307:2011(E), ISO12176-1, and DVS2207/1(08/2007) international standards.
Comprehensive 24-month international warranty covering all components.
