Name: 160MM Hdpe Pipe Thermofusion Welding Machine 220V
Brand: HEBEI ZEMO TECHNOLOGY CO., LTD.
SKU: SMD-B160/50H
Price: 50.00 USD
Availability: InStock

Home Products Manual Butt Fusion Welding Machine

160MM Hdpe Pipe Thermofusion Welding Machine 220V

Product Details:

Place of Origin:	China
Brand Name:	ZEMO
Certification:	CE , ISO
Model Number:	SMD-B160/50H

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	negotiation
Packaging Details:	Polywood cases
Delivery Time:	3-7 working days after payment
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	300 set/month

Contact Now

Detailed Product Description

Product Name:	HDPE Butt Fusion Welding Machine	Pipe Size (mm:	50-160MM
Heating Plate Max. Temp.:	270 ℃	Temp.deviation In Surface (170-250 ℃):	≤±7℃
Pressures Adjustable Ranges:	0-6.3Mpa	Working Voltage:	220V , 50/60HZ , Single Phase
Heating Plate Power:	1KW	Planing Tool Power:	1.1KW
Hydraulic Unit Power:	0.75KW	Total Power:	2.85KW
Weight:	260KG	Guarantee:	24 Months
Highlight:	Hdpe Pipe Thermofusion Welding Machine , 220V Thermofusion Welding Machine , 160MM Hdpe Pipe Welding Machine

220V 160MM Hdpe Pipe Thermofusion Welding Machine

DVS2207-1(08/2007) 160MM HDPE Butt Fusion Welding Machine

HDPE Butt Fusion Welding Machine Description

Hdpe Butt Fusion Welding Machine is able to weld pipes and fittings with material PE, PP and PVDF, operation easily and suitable for any complex work condition. It Consists of basic frame, hydraulic unit, planing tool, heating plate, support for planing tool& heating plate, and optional parts

When our hdpe butt fusion welding machine welds pipe together with data logger, the welding process is in a semi-automatic way, continuous repeat of the welding cycles and automatic control of preset parameters. Data Logger can store up to 1000 welding cycles and sum them into a encrypted EXCEL file. This report can be transferred to a PC/Laptop through a USB port.

HDPE Butt Fusion Welding Machine Specification

Product Name		DVS2207-1(08/2007) 160MM HDPE Butt Fusion Welding Machine
Model		SMD-B160/50H
Pipe size (mm)		50,63,75,90,110,125,140,160
Application		Butt Fusion Welding HDPE pipe
Heating plate Max. Temperature		270℃
Temp.deviation in surface (170-250 ℃)		≤±7℃
Pressures Adjustable Ranges		0-6.3Mpa
Working Voltage		220V , 50/60HZ , single phase
Heating plate power		1KW
Planing tool power		1.1KW
Hydraulic unit power		0.75KW
Total Power		2.85KW
Weight		106KG
Packing	Cases	3 plywood cases
	Volume	0.58 CBM

160MM Hdpe Pipe Thermofusion Welding Machine 220V 0

HDPE Butt Fusion Welding Machine Available options:

Data logger

Support roller

Stub end holder

Electric Crane

Machine body trolley

Different inserts (single insert, ISO inserts)
