| Place of Origin: | China |
| Brand Name: | ZEMO |
| Certification: | CE , ISO |
| Model Number: | SMD-B315/90H |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Polywood cases |
| Delivery Time: | 3-7 working days after payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300 set/month |
| Product Name: | 315MM Thermofusion PVDF Hydraulic Butt Fusion Welding Machine | Pipe Size (Inch): | 90-315MM |
|---|---|---|---|
| Heating Plate Max. Temp.: | 270 ℃ | Temp.deviation In Surface (170-250 ℃): | ≤±7℃ |
| Pressures Adjustable Ranges: | 0-6.3Mpa | Working Voltage: | 220V , 50/60HZ , Single Phase |
| Heating Plate Power: | 3.5KW | Planing Tool Power: | 1.1KW |
| Hydraulic Unit Power: | 0.75KW | Total Power: | 5.35KW |
| Weight: | 216KG | Guarantee: | 24 Months |
| High Light: | 315MM Hydraulic Butt Fusion Welding Machine,Thermofusion Hydraulic Butt Fusion Welding Machine,PVDF hydraulic butt fusion machine |
||
HDPE Butt Welding Machines have become very popular in the machinery industry in the last couple of years. HDPE Butt Welding Machines are able to be found everywhere in the world right now.
The mouth part of the HDPE butt welding maachine’s piece is heated to 200-220 degrees to ensure a smooth correction. Then, by touching each other, they will be united. By pressing tight, holding specified areas on the heater, waiting under pressure, and combining, hdpe butt welding is performed. When using this method, it has one-to-one properties to the original
All designed according to ISO21307:2011(E),ISO12176-1 and DVS2207/1(08/2007)
| Product Name | PVDF Hydraulic Butt Fusion Welding Machine | |
|
Model
|
SMD-B315/90H
|
|
|
Pipe size (Inch)
|
90-315MM |
|
| Application | PE Pipe & Fitting Welding | |
|
Heating plate Max. Temperature |
270℃
|
|
|
Temp.deviation in surface (170-250 ℃)
|
≤±7℃
|
|
|
Pressures Adjustable Ranges
|
0-6.3Mpa
|
|
|
Working Voltage
|
220V /110, 50/60HZ , single phase
|
|
|
Heating plate power
|
3.5KW
|
|
|
Planing tool power
|
1.1KW
|
|
|
Hydraulic unit power
|
0.75KW
|
|
|
Total Power
|
5.35KW
|
|
|
Weight
|
216KG
|
|
|
Packing
|
Cases
|
3 plywood cases
|
|
Volume
|
0.99CBM
|
|
FAQ :
1. Who are we?
Zemo Welding Machinrey Co.,LTD (ZEMOWELD) is one of comprehensive manufacturer of Thermoplastic Welding Equipment and an experienced professional exporters in China
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Butt Fusion Machine,Electrofusion Welding Machine,PPR Welding Machine,Automatic Plastic Welding Machine,Workshop Fitting Welding Machine,HDPE Fitting,Plastic Pipe Tools
4. Why should you buy from us not from other suppliers?
1. Welding equipment has CE,ISO,BV, SGS certification, as well as domestic welding industry laboratory CNAS certification. 2. 20 years of experience in welding machine export sales 3. Welder supply range from 40mm to 3000mm
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Russian
