| Place of Origin: | China |
| Brand Name: | ZEMO |
| Certification: | CE , ISO |
| Model Number: | SMD-NS800D |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiable |
| Packaging Details: | AL boxes |
| Delivery Time: | 3-5 days after payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 SET/week |
| Product Name: | Geomembrane Welding Machine | Input Voltage: | 220V ,50/60HZ |
|---|---|---|---|
| Application: | Geomembrane Welding | Power: | 800W /1000W |
| Overlap Width: | 10CM | Welding Speed: | 0.5-5.0m/min |
| Heating Temprature: | 20-450 ℃ Adjustable | Seam Width: | 12.5 Mmx2, Interior Cavity 12mm |
| Welding Thickness: | 0.2-1.5mm | Warranty: | 2 Year |
| High Light: | Portable Geomembrane Welding Machine,800W Geomembrane Welding Machine,Hot Wedge Welder SMD-NS800D |
||
SMD-NS 800D Hot Wedge Welder is advanced hot wedge welder with light, small structure for welding 0.2-1.5mm.
HDPE,LDPE,PVC,EVA,ECB,PP, thermoplastic material, which used in waterproofing projects like tunnels, subway, water conservancy, farming, solid waste landfills, chemical mining industry, sewage treatment, roofing, etc.
Geomembrane Welding Machine Specification
| Product Name | Geomembrane Welding Machinke |
| Voltage: | 220V/ 110V ±10% |
| Frequency | 50/60Hz |
| Power: | 800W or 1000W |
| Welding speed: | 0.5-5m/min |
| Heating temperature: | 0-450C |
| Thickness of material: | 0.2mm-1.5mm( PVC: 0.2-2.0mm ) |
| Overlap width: | 10cm ( Can be customized) |
| Welding width: | 12.5mm×2,interior cavity 12mm( can be customized ) |
| Seam strength: | ≥85% base material (tensile resistant in shear direction) |
| Weight: | 5.0KG |
| Insulation class: | Class ll |
| Usage | Welding geomembrane,such as PE PVC EVA and so on |
Geomembrane Welding Machine Factory View
Geomembrane Weldng Machine Spare Parts
Geomembrane Weldng Machine Tips:
If the thickness of HDPE geomembrane is 0.2-1.0 mm, you can choose silica pressure roller;
If the thickness of HDPE geomembrane is 1.0-1.5 mm, you can choose steel pressure roller.
You can choose silica pressure roller to weld PVC geomembrane because PVC is soft.
How about your Guarantee and Service ?
All designed according to ISO21307:2011(E),ISO12176-1 and DVS2207/1(08/2007)
International warranty: 24months.
Any parts broken or does not work under normal operating,we are free to provide.
