| Place of Origin: | China |
| Brand Name: | ZEMO |
| Certification: | CE , ISO |
| Model Number: | SMD-NS800 |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiable |
| Packaging Details: | AL boxes |
| Delivery Time: | 3-5 days after payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 SET/week |
| Product Name: | Geomembrane Welding Machine | Input Voltage: | 220V ,50/60HZ |
|---|---|---|---|
| Application: | Plastic Welding,Geomembrane Welding,EVA,PVC Welding,Welding PE | Power: | 800W |
| Overlap Width: | 10CM | Welding Speed: | 0.5-5.0m/min |
| Heating Temprature: | 20-450 ℃ Adjustable | Seam Width: | 12.5 Mmx2, Interior Cavity 12mm |
| Welding Thickness: | 0.2-1.5mm | Warranty: | 2 Year |
| High Light: | PVC Geomembrane Welding Machine,EPDM Geomembrane Welding Machine,Automatic Plastic Hot Wedge Welder |
||
SMD-NS800/800D series Geomembrane welding machine is our new developed products, which can weld geomembrane of various thickness and are applicable for welding of all thermal-fused material such as LDPE, PVC, HDPE, EVA, PP and so on.
| Product Name | Geomembrane Welding Machine | |
|
Model
|
SMD-NS800
|
|
|
Input Voltage
|
220V/110V ,50/60HZ
|
|
|
Power
|
800W
|
|
|
Overlap Width
|
10CM
|
|
|
Welding Speed
|
0.5-5.0m/min
|
|
|
Seam Width
|
12.5MM*2 Interior Cavity 12mm
|
|
|
Heating Temperature
|
20-450℃ Adjustable
|
|
|
Welding Thickness
|
0.2-1.5mm
|
|
|
Net Weight
|
5.0KG
|
|
Geomembrane Welding Machine Features
1.Contorl System:Advanced intelligent digital control system which temperature and speed readed on LCD screen.2.Pressure
Adjustment System:advanced"T"jib design and pressure regulation structure.
3.Pressure Roller:special stainless steel pressure roller with strong pressure force.
4.Hot Air Heating System:advanced hot air heating system perfects the welding quality even if corrosive material and bad working
environments.
Geomembrane Weldng Machine Customer operation
