CNC Saddle Fitting Fabrication Machine Automatic Lateral Wye 45 Degree 380V CE Articulating Clamp

Where standard tee connections fall short, the CNC Lateral Wye Saddle Fitting Fabrication Machine delivers precision-engineered 45-degree branch connections for HDPE and PE pipeline systems. This specialized CE-certified automatic CNC machine operates on 380V industrial power and is purpose-built for fabricating lateral wye (Y-branch) connections, an essential component in pipeline networks where flow direction changes or dual-branch configurations demand angled, non-perpendicular connections.

Lateral wye connections present unique fabrication challenges compared to standard 90-degree tee joints: the angled saddle interface requires asymmetric heating plate geometry, offset clamping alignment, and precisely calculated fusion pressure vectors to ensure uniform bond strength around the entire elliptical fusion surface. This CNC machine addresses all these challenges with a proprietary articulating clamp system that automatically adjusts to the required branch angle from 30 to 60 degrees while maintaining perfect alignment between the main pipe, saddle fitting, and heating element.

The advanced servo-driven angle positioning system, combined with real-time laser measurement feedback, ensures that every lateral wye connection meets the geometric tolerance requirements of DVS 2207-1 and ISO 21307 standards. An integrated cooling station with programmable dwell time prevents thermal distortion during the critical solidification phase.

1. Articulating Angle Clamp System: Proprietary servo-driven clamping mechanism automatically adjusts to branch angles from 30 to 60 degrees, enabling production of 45-degree lateral wye, 30-degree service branch, and custom-angle connections on a single machine platform
2. Asymmetric Heating Plate Technology: Purpose-designed heating plates with zone-controlled heating elements compensate for the elliptical fusion surface geometry, delivering uniform 270°C temperature distribution across the entire saddle interface
3. Automatic CNC Operation with CE Compliance: Full CE certification with PLC-controlled automatic fusion cycles eliminates operator-dependent variables. The system controls heating time, fusion pressure, cooling duration, and angle verification autonomously
4. 380V Three-Phase Industrial Power: 380V/50Hz power configuration supports high-torque servo motors for angle positioning and consistent hydraulic pressure delivery, suitable for continuous workshop production environments
5. Laser-Guided Angle Verification: Real-time laser measurement system verifies branch angle within 0.5 degrees before fusion cycle initiation, preventing costly rework on completed assemblies
6. Universal Pipe Compatibility: Modular clamping inserts accommodate HDPE, PE80, PE100, PP, and PVDF pipes from 315MM to 630MM diameter, with quick-change tooling for material and size transitions under 10 minutes
7. Programmable Multi-Angle Recipe Storage: CNC memory stores fusion parameters for up to 100 angle/material/diameter combinations as named recipes, supporting rapid production changeover in mixed-batch fabrication environments

The SHM630-WY45 lateral wye fabrication machine serves specialized pipeline applications where flow splitting or angled branch take-offs are required. Key application areas include irrigation network distribution headers with angled lateral take-offs, industrial process piping requiring Y-type flow dividers, fire protection ring main branch connections, and drainage network collector systems with oblique inlet connections. The programmable angle flexibility makes this machine particularly valuable for custom fabrication workshops serving diverse project specifications.

Each machine is shipped in a reinforced plywood case with molded foam inserts for the PLC control cabinet and precision servo components. All hydraulic lines are capped and labeled, and the articulating clamp mechanism is secured in transport position with locking pins. Factory acceptance testing includes a complete 45-degree lateral wye fabrication cycle with HDPE pipe, verified by laser angle measurement and peel-test inspection of the fusion joint. ZEMOWELD provides 2-year comprehensive warranty covering all mechanical, hydraulic, and electronic components, with remote diagnostic support via video call and express spare parts delivery.
