1000mm HDPE Saddle Fusion Machine

1000mm HDPE Saddle Fusion Machine

  • 1000mm HDPE Saddle Fusion Machine
  • 1000mm HDPE Saddle Fusion Machine
1000mm HDPE Saddle Fusion Machine
Product Details:
Place of Origin: China
Brand Name: ZEMO
Certification: CE, ISO
Model Number: SHM1000
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: negotiation
Delivery Time: 15 working days after payment
Payment Terms: D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 SETS/Week
Contact Now
Detailed Product Description
Product Name: HDPE Reducer Welding Machine For Fabricating Reducing Tee Size: 1000mm
Material: HDPE , PP, PE Pipe Voltage: 380V
Warranty: 2 Years Heating Plate Power: 12KW
Drill Motor Power: 3KW Hydraulic Unit Power: 0.75KW
Dimension(l*w*h): 1020X600X1200MM Application: Reduce Tee Made
High Light:

1000mm Saddle Fusion Machine

,

HDPE Saddle Fusion Machine

,

Smooth saddle fusion machine

1000mm HDPE Saddle Fusion Machine

1000mm HDPE Saddle Fusion Machine  introduction



A saddle socket fusion machine, also known as a saddle fusion machine or saddle welding machine, is a specialized tool used for joining plastic pipes through a fusion welding technique. It is commonly used for connecting branch pipes to existing main pipes, typically in applications such as water distribution systems, irrigation systems, and industrial piping networks.



The saddle socket fusion process involves heating the surface of the main pipe and the saddle fitting simultaneously using a heating element or heating plate. Once the surfaces reach the appropriate fusion temperature, the saddle fitting is pressed onto the main pipe, creating a secure and leak-proof joint as the melted plastic material fuses together. The fusion process typically requires consistent pressure and controlled cooling to ensure a strong bond.



Saddle Fitting Fusion Welding Machine Data Sheet



Product Name

1000mm HDPE Saddle Fusion Machine

Model

SHM1000
Heating Plate Power  1.5KW
Application  Recduce Tee Made
Hydraulic Unit Power  0.75KW
Drill Motor Power  16.5KW
Working Voltage 380V
Size  Main pipe 560-1000mm . Branch pipe 160-500MM
L*W*H 1020X600X1200MM
Weight 1900KG



Saddle Fitting Fusion Welding Machine Advantage

1.Efficiency: Saddle fitting fusion welding machines are designed to increase efficiency in the welding process. They enable fast and precise welding of saddle fittings onto pipes or other structures. This reduces the time required for welding operations, resulting in increased productivity.



2.Accuracy: These machines ensure accurate and consistent welding results. They are equipped with advanced technology and controls that allow for precise alignment and positioning of the saddle fitting. This helps in achieving high-quality welds with minimal errors or defects.



3.Versatility: Saddle fitting fusion welding machines are versatile tools that can be used for various applications. They are suitable for welding different types of materials, including polyethylene (PE), polypropylene (PP), and other thermoplastic materials commonly used in piping systems. Their adjustable features make them adaptable to different pipe sizes and configurations







1000mm HDPE Saddle Fusion Machine 0






1000mm HDPE Saddle Fusion Machine 1

Greeting from ZEMO in China! ZEMOTECH is one of comprehensive manufacturer of Thermoplastic Welding Equipment and an experienced professional exporters in China. Our main products: Butt Fusion Machine,Socket Fusion Machine,Electrofusion Machine, Hot Air Welders,Hot Air Welding Machine, Extrusion Welders, Geomembrane Overlap Wedge Welders,Band Saw,Cutting Machine,& Welding accessories.
